Craftsman Plan 5738-00008

What's Included in these plans?

• Cover Sheet with general notes and artists rendering
• Heated/Finished square footage calculations from outside of exterior studs, does not include decks, porches, garages, unfinished basements, or attic space.
• Foundation Plan 1/4"=1'-0" (includes location and sizes of foundation walls, slabs, footings, and grade beams)
• Floor Plans at each level 1/4"=1'-0"  (includes door and window locations and sizes, all dimensions, room sizes,  location of cabinetry and built-ins)
• Floor Framing plans at each framed floor level 1/4"=1'-0" (includes floor framing member sizes and spacing and interior bearing walls and posts)
• Exterior Elevations  1/4"=1'-0"  (includes elevations of all sides of building with all exterior materials, window and door openings, detail callouts, floor heights
• Building Section  1/4"=1'-0"  (includes a section through the entire building showing construction materials, floor levels, foundation, roof, floors and walls)
• Interior Elevations 1/4"=1'-0"  (Cabinet elevations at bathrooms, kitchen and laundry rooms) -Roof Plan 1/4"=1'-0"  (includes "birds eye" view of roof with roof slopes, valleys, ridges, saddles, crickets, and locations of gutters and downspouts)
• Electrical Plans at each finished level 1/4"=1'-0"  (includes suggested locations of lighting, switches, outlets, thermostats, fans, cable TV, data/telephone, and door bells)
• Wall Sections and Details  Scale varies (includes necessary foundation, framing, and trim and finish details)

What's not included:  House plans do not typically include mechanical, plumbing, or truss drawings. Additionally, some jurisdictions require a local architect or engineer to make adjustments to the plan to comply with local building codes. We advise you to check with your local building department regarding codes. For more information, visit the What's Included in Our Plans page.
