Luxury House Plan 168-00082

Sq Ft6,075
Beds5
Baths5
1/2 Baths1
Stories2
Cars3
Width65' 0"
Depth69' 0"
Images copyrighted by the designer. Photographs may reflect a homeowner modification.

Floorplan Drawings

 REVERSE  PRINT  DOWNLOAD Images copyrighted by the designer.
Floorplan 1 for House Plan #168-00082
Floorplan 2 for House Plan #168-00082
Floorplan 1
Floorplan 1 for House Plan #168-00082
Floorplan 2
Floorplan 2 for House Plan #168-00082


Frequently Asked Questions

COST TO BUILD REPORT

What's Included in these plans?

  • Floor Plan
    Each of our distinctive plans comes with a professionally designed, fully dimensioned Floor Plan indicating the size and location of all walls, doors, windows and special features. Fireplace details are included where applicable. Door and window schedules are included to provide detailed information regarding opening sizes and window types. Each plan is supplemented with specific and general notes, room labels, area calculations, light and ventilation calculations, and ceiling heights.
  • Kitchen & Bath layouts
    The general layout of kitchens and baths is shown on the floor plan and include fixtures and cabinetry.
  • Elevations
    All Plans have scale exterior elevations that show front, rear, left and right sides. These are detailed representations that graphically display heights of significant building features and design elements. Exterior finishes, ornamental design elements, roof type and roof pitch are generally shown on the elevations.
  • Sections
    Wall Sections and Building Sections are incorporated into the set to show a profile slice of the building to indicate recommended methods and materials of construction, including second floor joist framing.
  • Structural Plans
    All building structural requirements are engineered and fully detailed with beam, ledger, footing, column, and header schedules, notes and any special condition (like stairs and residential elevators) and framing details. Connector schedules are based on engineered uplift calculations.
  • Foundation Plan
    Most of the Aronson & Associates Foundation Plans come with engineered reinforced slab foundations. These include thickened edge and footing sizes, section markers, and mechanical equipment locations, as well as all building code related notes.
  • Roof Plan
    Roof and Roof Framing plans are aerial views showing roof slopes, ridges, hips and valleys. In addition to the basic roof lines, our roof plans have specifically engineered truss drawings that show the length, spacing and layout of all roof structural members.
  • Mechanical Plans
    Most plans have separate, fully engineered Mechanical Plans that show detailed information regarding building mechanical systems, and specific equipment details and specifications.
  • Electrical Plans
    Electrical Plans are included separately to provide the level of detail you could only expect from an experienced architect. These drawings fully represent the location of all fixtures, switches and outlets. Lighting calculations, electrical symbol legend, typical Arc Interrupting Current calculations, riser diagrams and panel schedules are also included.
  • Plumbing Plan
    Plan sets include the layout of all plumbing fixtures and normally have a plumbing isometric riser diagram with each fixture labeled.

ASK US A QUESTION

Name:
E-mail Address:
Password: (for robots)
Your Question:

To request a modification quote, please use the Modification Request Form.

About This Plan

The warm vibrant colors, tile roofing, stucco façade, stunning ironwork and extensive balconies evoke the tradition of homes located off the coast of the Mediterranean Sea. This type of architectural style is growing in popularity across the country and it is easy to see why, with its stunning exterior and modern interior floor plan. Approximately 6,000 square feet of bliss includes five bedrooms, 5+ bathrooms and a three car garage. The towering gallery entry leads into an equally stunning foyer with a curved staircase on one side and the den directly across from it. The den features a trey ceiling, striking window views and presents the perfect environment in which to entertain intimate friends and business associates. The formal living room is an outstanding space with its soaring coffered ceiling, fireplace, bar area and graceful bowed window views. The formal dining room with rear covered patio access is adjacent to the living room and makes an excellent space in which to entertain. The media room with wet bar is situated off the foyer and is perfect for watching movies or just “hanging out.” The designer chef’s kitchen features a large center island, breakfast bar, separate walk-in pantry and butler’s pantry and is open to the café and family room. This area is a traditional family space and provides access to the rear covered patio. A cabana bath and large utility room with laundry chute are included on the main level of the home along with the guest suite. The guest suite is fit for royalty and features private access to the rear courtyard, a spacious bedroom with trey ceiling and a double closet along with a walk-in closet. The guest bath is highlighted by dual vanities, a separate shower and garden tub. A powder room and residential elevator for infirmed or elderly guests completes the first floor the home. As you ascend the staircase or elevator, you are greeted with a bridge hallway which is open to the living room below. Bedroom two is spacious with a walk-in closet, private bath and French doors leading to a private balcony. Bedroom three and four enjoy private baths, walk-in closets and private balconies. The master retreat is simply luxurious and is accessed through French doors which lead to the morning kitchen and vestibule. There are oversized his and her walk-in closets; hers is an enviable size of many bedrooms. The master bedroom features an enormous bedroom with trey ceiling and beautiful window views and provides access to the private covered balcony. The master bath is heavenly and the piece de resistance is the large roman spa tub; also included is an oversized shower, separate dual vanities and his and her compartmentalized toilets. This home is definitely fit for a king, and his queen and provides old world charm, modern amenities and an absolutely stunning floor plan.
