Southern House Plan 5633-00215

Sq Ft2,487
1/2 Baths1
Width96' 6"
Depth66' 0"
Images copyrighted by the designer. Photographs may reflect a homeowner modification.

Floorplan Drawings

 REVERSE  PRINT  DOWNLOAD Images copyrighted by the designer.
Floorplan 1 for House Plan #5633-00215
Floorplan 1
Floorplan 1 for House Plan #5633-00215

Frequently Asked Questions


What's Included in these plans?

  • Heated and Cooled Square Footage calculations are made from outside the exterior frame wall and do not include decks, porches, garages, unfinished basements, bonus or attic space.
  • Artist Rendering
  • Foundation & Floor Plans (1/4"=1')
  • Front Elevations (1/4"=1'), Sides & Rear Elevation (1/8" or 1/4" = 1")
  • Kitchen and Bath Elevations (1/4"=1') **
  • Miscellaneous Details (1/4" to 3/4"=1')
  • Stair Section (1/4" to 3/8" = 1')
  • Roof Overview Plan (scale varies) **
    ** Some plans in this series do not provide cabinet elevations or roof overview.  Please call to verify.
    This home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as suggested locations for light fixtures, outlets and switches.
    This plan includes the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
    The kitchen and bath elevations show the arrangement of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
    Some details are included for interior and exterior conditions that require more specific information for their construction.
    This is a "bird's eye" view showing the roof slopes, ridges, valleys and any saddles.


E-mail Address:
Please leave blank:
Your Question:

To request a modification quote, please use the Modification Request Form.

About This Plan

This exquisite Ranch house plan has a sprawling front exterior with unique architectural design features including an expansive covered porch, brickwork, cedar shakes and unusual roof lines. Plenty of usable and comfortable living space define the home’s interior which is comprised of three bedrooms and two plus bathrooms in approximately 2,487 square feet. Additional square footage is offered in the basement foundation which almost doubles the size of the home. This beautiful southern house design encompasses detailed and space definition that makes entertaining enjoyable and effortless. An enormous great room greets you as you enter the home and features a corner fireplace and multiple window views highlighting the rear covered patio which boasts of soaring ceiling heights. A see-thru fireplace is the centerpiece of the hearth/dining room bringing warmth and comfort into the space including the kitchen and breakfast area as well. The gourmet kitchen has an open bar area, a separate pantry and plenty of work and prep space. A private study/home office is situated at the front of the home, offers a closet area, and presents a great option in which to meet with business associates and close friends. There is a large interior laundry/mudroom conveniently located off the two car oversized garage which contains extra storage space.
The family bedrooms and bathrooms are situated on the opposite side of the home for privacy and feature two spacious bedrooms; both have generous closet space and double window views. A shared hall bath offers double sinks and there is a hall linen closet as well. The master retreat is gorgeously designed and represents the finest in luxury and privacy. The master bedroom features vaulted ceilings and there is an option for coffered ceiling work. The rear of the room houses an oversized bay window and there is private side patio access for enjoying morning coffee. The master bath features dual vanities, a soaking tub and a separate shower. There is an enormous walk-in master closet with linen storage at the rear of the bath for convenience. This tastefully designed home features a striking exterior façade and a fully functional interior floor plan.
