Florida Plan 575-00030

What's Included in these plans?

• Elevations:  Drawn at 1/8" to 1/4" = 1'0" Scale and Includes:
  Material Labels
  Floor-To-Floor Heights
  Roof Slope Indicators
• Floor Plans:  Drawn at 1/8" to 1/4" = 1'0" Scale and Includes:
  Door and Window Sizes
  Completely Dimensioned Floor Plan
  Room Labels and Interior Room Sizes
• Electrical Layouts:
  Building Section Markers
  All Electrical Outlets, Fixtures and Switching
• Foundation or Slab Plan:  Drawn at 1/8" to 1/4" = 1'0" Scale and Includes:
  Floor and Deck Joist Sizes, Spacing and Direction
  Rough-In Plumbing Location (if applicable)
  Mechanical Equipment Locations (if applicable)
  Electrical Locations (if applicable)
• Roof Design Plan:  Drawn to 1/8" to 1/4" = 1'0" Scale and Includes:
  All Beam and Header Heights and Locations
  All Hips, Gables, Ridges and Valleys
  Building Section Markers
• Building Sections:  Drawn to 1/8" to 1/4" = 1'0" Scale and Includes:
  Floor Joist Size and Spacing
  Floor-To-Floor Heights
  Non-Typical Plate Heights Indicated
• Typical Wall Sections:  Drawn at 1/8" to 1/2" = 1'0" Scale and Includes:
  All Labels Indicating Wall Construction
  Foundation Wall Thickness and Reinforcing
  Insulation Type and Thickness
• Miscellaneous Notes and Details:
  Miscellaneous General Notes
  Stairway Details (if applicable)

What's not included:  House plans do not typically include mechanical, plumbing, or truss drawings. Additionally, some jurisdictions require a local architect or engineer to make adjustments to the plan to comply with local building codes. We advise you to check with your local building department regarding codes. For more information, visit the What's Included in Our Plans page.
